Aluminum foil rolling mill
Product Introduction
Aluminum foil due to its strong, light weight, non-toxic, tasteless, moisture-proof, heat insulation, opaque, corrosion
resistance, high conductivity, non-magnetic; Easy processing, coloring, printing, gloss and a series of advantages. Therefore, it has become the best material for food, beverage, tea, cigarettes, medicine, cosmetics and other packaging, and it is also an important material for manufacturing capacitors, cables, architectural decoration, textiles, vehicles, ships, aviation and other industries.The development of aluminum foil industry depends on the development of aluminum foil rolling mills. Since the industrialization of aluminum foil production in China, the most advanced technology and equipment of aluminum foil rolling in the world have been introduced, so that China's aluminum foil production has developed in the direction of large-scale, high-speed, automation and quality.
Hongteng company closely follow the world's cutting-edge technology, constantly absorb and digest the latest technology, independent development, design, processing and manufacturing.The aluminum foil roughing mill is used for receiving sheet metal from cold rolling mill, 0.5 rolled to the thinnest 0.012 single zero aluminum foil, which is supplied to the foil finishing mill or the foil finishing mill for continuous rolling.
Production Process
The billet to be rolled is lifted to the inlet coil support, transported to the uncoiler by the coil trolley for tightening, rolled by the inlet deflector roll, the inlet tensioning roll, the work roll rolling, the outlet tensioning roll, and the flattening roll. After the winding is completed, the coil trolley is transported to the outlet coil support, and the sleeve lifting device removes the sleeve from the uncoiler. The sleeve is transferred to the coiling side at the bottom of the mill, and is sent to the coiler by the sleeve lifting device to complete one pass of rolling.
0.5-0.012 Thinnest sheet |
这里是答案
VIDEO PRESENTATION
PRODUCT DISPLAY
Aluminum foil rolling mill
Aluminum foil rolling mil2
Aluminum foil rolling mil3
